| Screen size | 70inch |
| Active Display Area | 1538.88 × 865.62 mm (H×V) |
| Aspect Ratio | 16:9 |
| Visual Angle | Horizontal170 / Vertical170 |
| Panel | Original LGD/BOE/AUO A grade brand panel |
| Brightness | 350cd/m2 |
| Contract Ratio | 3000:1 |
| Resolution Ratio | 3840*2160 |
| Color Components | 16.7M |
| Response Time | 6ms |
| Power Consumption | 220W |
| Standby power consumption | ≤2W |
| Glass | Standard tempered glass |
| Android Touch | IR 20-points touch screen |
| Windows Touch | IR 20-points touch screen |
| Power Supply | Input: AC110-240V-50/60Hz |
| Material | Metal and 4mm thickness tempered glass |
| Color of Shell | Black |
| Life of Panel | 30000-50000Hours |
| Dimension of Machine | TBD |
| Carton box packing | TBD |
| Photo formats | JPEG ,BMP ,GIF ,PNG |
| Audio formats | MP3,WAV,WMA |
| Video formats | MP4,AVI,DIVX,XVID,VOB,DAT,MPG,MPEG,RM,RMVB,MKV,MOV,HDMOV,M4V, |
| OSD Language | English, Chinese, French, German, Italian, Spanish,Arabic |
| Speaker | 2*10W |
| Working Temperature | -10℃-50℃ |
| Storage Temperature | -20℃-60℃ |
| Accessory | Power Cable, English Manual, IR Remote Controller, Touch Pen, WIFI antenna, Wall mounted bracket, Movable floor stand |
| Android Mainboard Configuration |
| CPU | MSD6A648 Quad core Cortex A53*4 1.5GHz |
| RAM | DDR3 1G(2G optional) |
| Memory | 8G(16G optional) |
| OS | Android 6.0 |
| SD card | Support Max 128GB TF card |
| Front port Configuration |
| Port | USB2.0*2 HDMI in*1, USB touch*1 |
| Input/output port Configuration |
| Port | RS232*1, YPBPR in*1,HDMI in*2, RJ45*1, Touch USB*1, VGA in*1, VGA audio in*1, SD card*1, MIC in*1, USB3.0*2, RF-IN*1, SPDIF out*1, Earphone*1, VGA out*1 |
| OPS Configuration |
| CPU | I3/I5/I7 |
| Memory | DDR3 4G/8/16G optional) |
| SSD | 128G(256/512G optional) |
| OS | Beta Windows10 |
| Port | HDMI in*1, VGA in*1, USB2.0*2, USB3.0*2, RJ45*1, Audio out*1, Mic-in*1 |
